Fractional resurfacing is a new laser treatment modality that creates numerous microscopic thermal injury zones of controlled width, depth, and density that are surrounded by a reservoir of spared epidermal and dermal tissue, allowing for rapid repair of laser-induced thermal injury. This unique modality, if implemented with proper laser-delivery systems, enables high-energy treatments while minimizing risks.
Application
Skin resurfacing (to improve texture)
Pigmented lesions: age, brown or sun spots
Wrinkles around the eyes
Acne scars
Surgical scars
Melasma (mask of pregnancy)
Actinic Keratoses
Stress Urinary Incontinence
Relaxed Vagina
Labium Whitening
Dyspareunia
Colpoxerosis
Sexual satisfaction
Vaginal tightening
Advantages of System
1/ RF Laser Tube is more stable than traditional Glass tube, the machine is non serviceable
2/ With the RF laser Tube, the scanning depth can reach the derma layer , to accelerate the collagen re-growth.
3/ RF Laser Tube makes the scanning dot much thinner and less harm
4/ The Laser Tube frequency can reach more than 5000HZ, high scanner can get better treatment effect
5/ Four working modes ,Fractional, CW, Pulse, Ultra Pulse ,one machine can been used in widely in different surgery
6/ Special designed energy self-inspected and energy-replenishment system ,improving the stability and effect
Laser source | Metal RF co2 Laser Generator |
Laser Type | 10.6μm |
Output Power | 30W |
Focal length of working head | F=50mm 75mm 100mm |
Indication Beam | Red Diode Laser(650nm, ≤5mW) |
Transmission System | 7-Articulation Joint Spring Arm |
Smoke Exhausting System | Built-in air blow |
Cooling System | Air cooling |
Environmental temperature | 5°C~40°C |
Relative Humidity | ≤80% |
Power Supply | ~220V±22V,50Hz±1Hz |
Dimension | 52*68*3300px |
Weight | 35kg |
Working mode | |
Continuous | Power 1~30W step adjustable each 1 W |
Pulse | Power 1~30W step adjustable each 1 |
Interval time | 1~999ms |
Ultra pulse | Power 1~30W step adjustable each 1 Modulated frequency of 1000 Hz |
Pulse Duration | 90-1000μs |
Scanning mode | |
Scan mode | Ellipse, Rectangular, Triangular, Line, Square,hexagon,round |
Repeat Delay | 0.1s—- 5.0s |
Micro Pulse Energy | 5mJ—50mJ |
Treatment Level | 0.30%—–25.0% |
Passes | 1—–10 times |
Estimated Power | 24mJ–1000J |
Ellipes estimated power | 31mJ—-1000J |
Rectangular estimated power | 24mJ—-981J |
Treatment area | 0.1*0.1mm, —– 15*15mm.(F=50mm) |
Handpiece Velocity | 0.1—–225px2/s |
Scanning Depth | ≤2.0mm |
Vaginal Mode | |
Continuous | 360 degree revolution |
Treatment depth | 100mm |
Treatment head diameter | 30mm |
Max Scanning diameter | 9*9mm2 |
Spot Size Diameter | 0.2-1.0mm |
Focus length | 150mm |
Suggestion parameter setting | 30-40mj/pin |
