Essential details
- Place of Origin:
Guangdong
- Brand Name:
TMlIPO
- Model Number:
TM-448
- IPL+ RF:
NO
- Style:
PORTABLE
- Warranty:
1 Year
- Type:
RF
- Feature:
Wrinkle Remover, Weight Loss, Skin Rejuvenation, Face Lift, Firming, musculoskeletal rehabilitation
- Plugs Type:
EU
- Application:
For Home Use, For Commercial
- Target Area:
Body, Face, Eyes, Legs/Arms, Neck/Throat
- RF polar:
Monopolar
- RF frequency:
448kHZ
- Power:
400W
- Energy:
1-50J
- Handle:
capacitive (CAP) handle and resistive (RES) handle
- Function:
cellulite removal, skin tightening, physiotherapy
- Voltage:
100-120V or 200-240V
- Treatment area:
Face Body Neck
What is RF System?
It is called diathermy(deep heating) which is the system to provide the treatment by generating heat in the human body.
What is CET?
Capacitive electric transfer (CET) is a method that allows the RF electrical current to be transferred "by capacity" (principle of the electrical capacitor) to the patient's body via a movable external application electrode. This is covered with an insulating film which acts as dielectric and the body acts as a second plate of the capacitor. A return plate closes the circuit. The electric circulation through the resistive medium formed by the live tissues increases its temperature.
CET concentrates the energy to the muscles and other tissues fluid. The action is localized surface or half deep.Selective heating of tissues stimulates the fibroblasts and promotes the production of collagen and elastin to achieve a firming effect,transfers heat to a deep subcutaneous fat layer,the technique of gentle massage followed by deep body massage to activate circulatory exchanges and accelerate the elimination of fat.
What is RET?
The resistive electrical transfer (RET), introduced in 1994, is different from the CET in that basically the application electrode is not insulated, allowing the current to be transferred directly to the patient with less dispersion, thus obtaining an increase in temperature at a greater depth.
RET focuses energy on all hard tissues such as joints, tendons and bones. The action is poly -articular and deep.It stimulates intra and extra cellular ion exchange restoring physiological cell electrical activity, accelerating the natural repair mechanisms of the tissue in a safe and secure way, the patient recovers as soon as possible.Both acute and chronic pathology fundamental goal of treatment focuses on reducing pain and inflammation and accelerate the healing process of tissue.
Monopolar RF takes that epidermis balances normal temperature, RF electric wave produces heat into deep skin as nuclear technique, based on assurance of skin comfortable, harmless, it uses RF electric wave to produce heat exchange, precisel. Attains skin deep, stimulates inner ion of body, colloid granule with electricity will be forced rapid movement, vibration or attrition, then produce heat energy.
RET Resistive Electric Transfer
- Stainless Steel Eletrode (not Insulated)
Current to be transferred directly to the patient
Go into 9~12cm depth of skin
Effective for the subcutaneous fat
CET Capacitive Electric Transfer
- Insulated Electrode
- Current to be transferred by Capacity to patient
Go into 3~5cm depth of skin
Effctive for skin liting, pain relief
Applications
- Face: Anti-aging, Cutaneous Sagging, Bags under the eyes, Double chin & neck.
Body: Flabby arms, Saddle bags& buttocks, Abdomen care, Cellulite reduction.
Physiotherapy care: Joint pain, Muscle pain, Neck pain, Back ache, Rheumatism, Oseto Arthrosis, Rehabilitation
Treatment - Body Shape Administration (Elimination of unwanted cellulite)
Face lifting by activating collagen
Abdomen Care
Better Blood Circulation
Faster Metabolism
